Quick Details

  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: yost
  • Model Number: HDPE
  • Material: PE
  • Specification: 200mm-1400mm
  • Length: 5.8 Meters
  • Thickness: 1mm-4mm
  • Standard: ISO
  • Color: Black
  • Application: Drainage
  • Product name: steel reinforced spiral HDPE drainage pipe
  • Certification: ISO Certificate
  • Feature: Light Weight
  • Type: Round Pipe
  • Size: 500mm
  • Usage: Construction Industry

Packaging & Delivery

Packaging Details: Packing:nude or according to specific customer needing suitable for long-time sea shipment
Delivery Detail: 7days
Product Description

 Application Area

Because the steel reinforced spiral HDPE drainage pipe is the perfect combination with all merits of ordinary non-press plastic pipes and high strength of steel reinforced segments, it can meet all demands in project applications completely. It can be widely used in gravity delivery with various media of corrosive or non-corrosive environments. Such as:

1. Road engineering: used for railway, highway seepage, drainage tube.

2. Municipal engineering: used as underground drainage, sewage pipe.

3. The landfill and sewage collection pipe.

4. Building engineering: used for building the rain water pipe, underground drainage pipe, drain pipe, vent pipe etc.

5. The industry: widely used for the waste pipe industry.

6. The large port, wharf engineering: large airport, port, wharf engineering drainage, sewage pipe etc.

Features and Benefits

1. Distinguished comprehensive performance

2. Safe and reliable ring stiffness

3. Light weight

4. Simple installation, good sealing and low cost of construction

5. Strong load capacity

6. Other advantages

Ways of Connection

Steel belt reinforced HDPE pipes can be connected through thermal-fuse or stainless coupling with sealing strip.

Physical Properties Of The Pipes

ItemRequirement

Ring Stiffness

(KN/m²)

SN4≥4
SN8≥8
SN10≥10
SN12.5≥12.5
Impact Property(TIR)≤10%
Flexible Ring

The sample is smooth,no reversed bending,no breakage,

the reinforcing ribs will not fall off the pipe body

Oven TestNo breakage and leakage
Creep Ratio≤2

Tensile Strength

(N)

200≤DN/ID≤300380
400≤DN/ID≤500600
600≤DN/ID≤800840
900≤DN/ID≤19001200
2000≤DN/ID≤26001440

Product Specifications

  Ring Stiffness Rank

Nominal Diameter

DN/ID.mm

Internal Diameter DN/ID.mm

SN8SN10SN12.5
≥8KN/m²≥10KN/m²≥12.5KN/m²

External Diameter

d.mm

External Diameter

d.mm

External Diameter

d.mm

200200224224
300300325325
400400438438
500500539539
600600644644644
700700745751751
800800852852862
900900963963963
10001000106310631063
11001100117311731173
12001200127312731273
13001300138513851385
14001400148514851485
15001500158515851585
16001600169316931693
17001700179317931793
18001800189318931903
19001900200320032003
20002000210521052121
21002100220522052205
22002200230723232323
24002400252725272533
26002600272927292735
28002800294429442952
30003000315031503154
32003200335433543362
Company Information

 Shandong Yost Import And Export Co.,Ltdwas founded in 2003. The company relies on Shandong Yost Group Co., Ltd, which has several factories, and mainly engaged in the foreign water conservancy engineering machinery and equipment, spare parts of overseas investment and export, technology consulting and construction services business. Shandong Yost Group is located in Jinan, which is very famous for its beautiful and magnificent spring in China. We has been engaged in collection of plastic pipe fittings, water meter, industrial valves and other water conservancy engineering equipment technology research and development, production and processing,sales and technical service for fifteen years. The parent company owns six plastic pipe production bases which produce PVC-U pipes, HDPE pipes, PVC-M pipes, PPR pipes and plastic pipe fittings.And Shandong Yost Group also owns a large industrial valve production branch.Scientific management and advanced technology make all our products pass the ISO9001 quality management system certification and ISO14001 environmental management system certification.

Since its establishment,Shandong Yost Import And ExportCo., Ltd insists on thephilosophy of "create value for customers, create wealth for shareholders," and actively expand international business relations of cooperation.By the end of 2014, our company has been established long-term cooperative relationswith customers from 89 countries and regions in the world, and to achieve export sales in 2014 more than US$18.3million, which established a solid foundation for the future long-term growth and development of the international business cooperation.

Packaging & Shipping

Packing:nude or according to specific customer needing suitable for long-time sea shipment



Delivery: within 7days after receipt of at sight L/C or 30% as advance payment by T/T
